Applications for exporting multi-layered frames of timber walls, floors, roof panels, and trusses

From Autodesk® Revit® to automated production lines

AGACAD CNC Exporters automatically assemble all framing members per user definitions and send all necessary data to various CNC machines and CAD/CAM production lines for flexible manufacturing of wood houses.

AGACAD currently offers CNC Exporters for the most popular CNC machines like Weinmann, Randek, Hundegger, EasyFrame, and Spida for timber frame prefabrication. The software can be adapted for any other CNC machines if needed. Existing exports can easily be adapted to other CNC machines if it reads the same file extensions. The BTL file extension, for example, is used worldwide.

AGACAD Wood Framing CNC Exporters must be used with AGACAD Wood Framing BIM software, which creates framing elements with all needed geometric and information data inside the Revit project and then the respective CNC Exporter converts the framed models into a format readable by your CNC machine.

      Compatible with Autodesk® Revit® 2023, 2022, 2021

Wood Framing featured by Autodesk

AGACAD becomes Autodesk AEC Industry Partner for Wood Framing

PRESS RELEASE – Vilnius, 4 February 2020

All CNC Exporters are customizable to fit users’ needs. AGACAD works one-on-one with clients who need to export to CNC to make sure the final product performs seamlessly and accurately.

Explore the available versions of AGACAD’s CNC Exporters for timber frames below ↓

      Compatible with Autodesk® Revit® 2023, 2022, 2021

Weinmann CAD/CAM Production Line WUP

This exporter generates files for Weinmann CAD/CAM production lines that read WUP extension files. Walls, floors, roof frames, and separate framing elements can be exported using this application. If there is a beam-processing machine included in your production line, then the WUP file can be used for simple processing like pre-cutting lumber for studs and beams for the timber framing.

Weinmann BTL and BTLx

This exporter generates files for Weinmann CNC machines that read the respective extension file. BTL file extensions are widely used around the world and in other machines too, so our existing installation can easily be adapted. Walls, floors, roof framing members, trusses, and separate framing elements can be exported using this application. Usually BTL and BTLx format processing goes for highly detailed and complex beams. BTLx is a newer format, whose use is not yet widespread.

Weinmann BTL CLT

This exporter generates files for Weinmann CNC machines that read BTL files for processing CLT (cross-laminated timber) panels. CLT models that have been framed using AGACAD’s Wood Framing CLT software can be exported to Weinmann’s using this application.

Randek CDT4

This exporter generates wall and floor frame files for automated Randek CAD/CAM production lines that read CDT files. The application allows you to export the main frame only, main frame and external layers, main frame and internal layers, main frame and external layers without siding, or all layers. The installation comes with basic and advanced settings. Advanced settings include interior/exterior sheathing nailing/stapling, sheathing trimming, siding trimming, and siding nailing settings.

Randek SPL728

This exporter generates special extension files for Randek’s SP700 series automatic cut saws. Wall and floor frames can be exported using this application. It currently works with main frames, but it can be adjusted for additional framing layers if needed.

Hundegger BVX

This CNC exporter generates files for automated Hundegger CNC machines that read BVX files. Walls, floors, roof framing members, trusses, and separate framing elements can be exported using this application.

Hundegger BVX2 Paneling

This exporter generates files for automated Hundegger CNC machines that read BVX files. CLT (cross-laminated timber) panels and sheathings can be exported using this application, though, the CLT panels must have been created using AGACAD Wood Framing CLT BIM software (as with our exporter for Weinmann BTL CLT above).

Easy Frame (EstiFrame) EZF

This CNC exporter generates files for automated EasyFrame CNC machines that read EZF files. Walls, floors, roof framing members, and separate framing elements can be exported using this application.

SPIDA SSF

This CNC exporter generates files for automated Spida Machinery CNC machines that read SSF files. In the current version, only Wall and Floor main frame elements can be exported using this application.

Would you like a quote or a live demo given by one of our experts? We are here to help.

Contact Us
