Direct export of wooden wall, floor, roof frames, and trusses from Revit® to SPIDA® machines


This CNC exporter generates files for automated SPIDA CNC machines that read SSF files. Walls, floors, roof framing members, and separate framing elements can be exported using this application.

AGACAD’s SPIDA SSF Exporter allows manufacturers of timber house frames to predefine operations and rules for automated CNC machines, including sawing, drilling, trimming, and marking operations for every framing member – directly from Revit. Walls, floors, roof framing members, trusses, or individual framing elements can be exported using this application.

SPIDA format is free standard for timber fabrication typically for processing beams that are more detailed and complex. Whereas SSF is a newer format that describes parts in a machine-independent geometry format and is not yet widespread.

      Compatible with Autodesk® Revit® 2023, 2022, 2021

The SPIDA SSF Exporter must be used with AGACAD Wood Framing Software, which creates the framing elements with all the necessary geometry and information data within the Revit project.
