Wood framing roof BIM software for Revit® for detailed design of prefabricated timber framed roof panel, truss & rafter systems
Wood Framing Roof lets Revit® users instantly create prefabricated wood frame roof panels, wooden truss and/or rafter systems of any shape or complexity with analytical lines, and generate custom shop drawings.
It’s a potent BIM workflow booster. Functions are versatile, parameters easy to control, and changes occur in real time. No more drafting – just design and decide, knowing you’ll get a high-quality model.
Compatible with Autodesk® Revit® 2023, 2022, 2021
Connectors, cuts, supports, tension braces and other details can be distributed based on predefined rules or connection types. They can then be modified or updated to suit the project design stage and the level of detail required. The layout and details of roof structural elements can be modified and updated whenever the project is changed.
Easy marking of trusses and rafters based on properties and location ensures accurate bills of materials and accurate assembly. And information for fabrication can be automatically generated with all desired views, schedules, and drawings for each structural element.
SNEAK-PEAK-VIDEOS
Prefabricated Wood Frame Roof Panels
Automated Rafter Framing
Auto-generate complex roof truss systems
POWERFUL FEATURES
Roof Panel Layout
PREFABRICATED ROOF PANELING
Plan roof panels easily and split them into segments for prefabrication which can be used in the roof framing process.
- Panel Layout Planning functions let you better understand how a roof will be divided. User can control every division line and can predefine rules to automate the division process.
- Initially an architectural roof can be divided into coarse partitions, or regions. Regions can be created automatically based on ends of roof ridges and bottom ends of valley rafters as well as windows and generic or system openings with predefined distances.
- Regions can be divided into panels using predefined spacing.
- Panels can be aligned and modified for an individual roof side or region and additionally split.
- A variety of automated splitting functions make it easy to get the needed result. Panels can be split in half a variety of ways: by maximum spacing, from the middle to both ends, in the middle and to both ends, from the initially selected end, or from both ends.
- Selected regions or panels can be joined, if needed.
- Creates individual panels for the selected roof side or for the whole roof.
- The full roof panels can later be taken to a new phase via their properties for better filtering and scheduling.
Roof+
for prefabricated panels
ROOF PANEL FRAMING
Automate wood framing work with prefabricated roofs in Revit projects.
Powerful, flexible, and easy to use Wood Framing Roof+ helps you make optimal choices, move much faster, and avoid errors at every BIM stage – from design and documentation to roof segment fabrication and construction.
- Create detailed, multilayer, prefabricated timber roof framing for your Revit model in a snap using fully customizable rules and templates.
- Frame large roofs with identical panels 10 times faster than using the standard Revit interface.
- Control joists, rim joists, nogging, bridging, blocking, and bracing placement. Configure openings, details, service hole positions, and more.
- Auto-distribute battens, secondary frame and roofing.
- Freely revise your Revit model simply by selecting the elements and properties you want to modify.
- Find structural and engineering clashes. Cut and frame openings according to predefined rules.
- One-click generation of shop drawings and cut lists. Real-time take-offs and views, plus automatic sorting and dimensioning.
- Optional export to any CNC machine and CAD/CAM production line, such as WEINMANN, Randek, etc.
- Roof frames and shop drawings update and adapt according to any changes.
- Export analytical lines of your wood frames to external structural analysis software at any stage of the design process.
Roof+
for rafter structures
RAFTER ROOF FRAMING IN REVIT
Automate wood framing work with rafter roofs from design and documentation to roof segment fabrication and construction.
- Automatically split an architectural roof by faces.
- Create detailed, multi-layer, timber rafter roof framing in a snap for your Revit model using fully customizable rules and templates.
- Frame an entire roof based on its 3D model including hip/valley rafters, ridges, girders, collars, battens, horizontal beams, sleepers, trimmers, etc.
- Auto-detect and frame roof openings, and cope ends of existing beams.
- Freely revise your Revit model by easily selecting the elements and properties you want to modify.
- Find structural and engineering clashes. Cut and frame openings according to predefined rules.
- One-click generation of shop drawings and cut lists. Get real-time take-offs and views, plus automatic sorting and dimensioning.
- Create detailed, multilayer, prefabricated timber roof framing for your Revit model in a snap using fully customizable rules and templates.
- Frame large roofs with identical panels 10 times faster than using the standard Revit interface.
- Control joists, rim joists, nogging, bridging, blocking, and bracing placement. Configure openings, details, service hole positions, and more.
- Auto-distribute battens, secondary frame and roofing.
- Freely revise your Revit model simply by selecting the elements and properties you want to modify.
- Find structural and engineering clashes. Cut and frame openings according to predefined rules.
- One-click generation of shop drawings and cut lists. Real-time take-offs and views, plus automatic sorting and dimensioning.
- Optional export to any CNC machine and CAD/CAM production line, such as WEINMANN, Randek, etc.
- Roof frames and shop drawings update and adapt according to any changes.
- Export analytical lines of your wood frames to external structural analysis software at any stage of the design process.
- Optional export to any CNC machine and CAD/CAM production line, such as WEINMANN, Randek, etc.
Truss+
FULL-POWER WOOD TRUSS CREATOR FOR REVIT
Generate wooden truss systems instantly, export analytical lines of elements to external structural analysis software, and auto-generate shop drawings tailored to your standards. Functions are versatile, parameters easy to control, and changes occur in real time.
- Build full truss systems in one go with the configurable 3D grid (escaping the limited and time-consuming nature of standard Revit truss family insertion).
- Easily assess options – such as wooden truss framing – in economic, structural, and systemic terms, to make the best design decisions.
- Create new parametric, uniquely-shaped truss families based on model lines and roofs for immediate use in your projects.
- Freely revise your Revit model, updating and adapting truss systems as needed.
- Get real-time take-offs and views, automatic creation of shop drawings and cut lists, and easy export to CNC machines.
Cut Opening
PRECISION OPENINGS FOR MEP SERVICES AND BUILDING STRUCTURES
Automatically create openings (with fire safety components as well) throughout a Revit model where ducts, pipes, cable trays, and conduits intersect with walls, floors, roofs, ceilings, beams, and columns. BIM solution Cut Opening creates openings with special holding details for structural beams.
- Automatically adds openings with predefined sizes in accordance with MEP line-based element sizes, categories, and system classifications.
- Automatically joins openings with predefined configurations.
- Automatically inserts Fire Dampers where ducts clash with walls, floors, ceilings, or roofs with fire rating.
- Automatically inserts structural openings for separate architectural and structural models.
- Enhances BIM-team work and deliverables for integrated project delivery (IPD).
Sort Mark
FLEXIBLE ELEMENT AND GRID RENUMBERING
Renumber Revit elements just the way you want, detect and renumber grids, determine swing direction and orientation (and add them as properties), recalculate shared coordinates, and much more.
- Detects and renumbers grid geometry.
- Renumbers grids automatically after they have been changed in the project.
- Powerful and flexible functions allow renumbering of any Revit elements (Doors, Windows, Beams, Columns, Pipes, etc.) in a number of different ways.
- Writes swing direction for doors into the door’s properties.
- Writes flip/mirror orientation for the selected elements.
- Recalculates shared X, Y, Z coordinates.
- Possibility of saving numbering settings under a separate name.
- Possibility of sorting elements in ascending/descending order.
- Creates new shared parameters, and many more functions.
Smart Views
MAKING VIEWS & PLACING DIMENSIONS FAST IN REVIT®
Get sections and elevation drawings for any building element easily using functions that create views and dimensions for selected elements quickly.
- Uses configurations instead of manual work
- Crops views to the element size
- Creates automatic dimensions based on defined configurations
- Applies view templates to all new views
- Creates the number of views you set in the configurations for multiple selected elements
- Renames views based on configurations
- Apply dimensioning rules to any Revit view or selected elements in view
Want to find out if this is the right solution for you? Our professionals can help you quickly find out how this software will benefit your design process.
FRAME YOUR PROJECT!
Don’t waste time reading technical documentation, and see that this is the solution for you! Our Expert will frame a part of your project, demonstrate software functionality, and share best practices and the most efficient way of framing, taking into account your current needs.
Duration: 2 hour. Cost: 280$/280€
You’ll leave the demonstration with:
– Part of your project already framed;
– Your questions answered;
– 30-day software trial;
– Support during the trial period.
CLIENT STORIES
Developed in compliance with standards and guidelines:
Eurocode 5: Design of timber structures – Part 1-1: General – Common rules and rules for buildings (EN 1995-1-1:2004: E)
Standards Australia AS 1684.2-2010 Residential timber-framed construction
Standards Australia AS 1720.1-2010 Timber structures – Design methods
New Zealand Standard ZS 3604:2011 / Timber Framed Buildings
CWC (Canadian Wood Council) Wood Design Manual including CSA O86 Standard and CWC Commentary on CSA O86 (2010).
National Design Specification® (NDS®) for Wood Construction (NDS 2015). American Forest and Paper Association (AF&PA). American Wood Council, Washington DC, 2015.
The Encyclopedia of Trusses. Alpine Engineered Products, Inc., 2003.
Truss Design Procedures and Specifications for Light Metal Plate Connected Wood Trusses / TPIC – 2014. Truss Plate Institute of Canada (TPIC), 2014.
Using Narrow Pieces of Wood Structural Panel Sheathing in Wood Shear Walls. American Plywood Association (APA), The Engineered Wood Association, Tacoma, Washington, 2005.
PRODUCT BROCHURES
Learn more about the AGACAD products by reading our selected brochures.
Videos
Testimonials
Panel Designer at Deltec Homes, Inc., USA
“My colleagues and I are very happy with the much-improved quality of the shop drawings I’m able to produce with Wood Framing Wall. I’m now working directly from the same model we generate all our plans from, so the potential for error is much reduced. I also now have control over my deliverables for the shop: I can include a lot more information than before, and I can exclude unnecessary information that used to clutter up panel sheets. One example of major improvements is that sheathing used to be just listed in a table, now it’s all drawn out graphically and easy to understand, which reduces the chance the shop could make a mistake.”
