Automated engineering and detailing BIM software for steel trusses & metal roof rafter systems design in Revit®

Metal Framing Roof lets Revit® users instantly create metal truss and/or rafter systems of any shape or complexity, perform structural analysis, and generate custom shop drawings. It gives a powerful boost to your BIM workflow. Functions are versatile, parameters easy to control, and changes occur in real time. No more drafting – just design and decide, knowing you’ll get a high-quality model.

Compatible with Autodesk® Revit® 2021, 2020, 2019

Connectors, cuts, supports, tension braces and other details can be distributed based on predefined rules or connection types. They can then be modified or updated to suit the project design stage and the level of detail required. The layout and details of roof structural elements can be modified and updated whenever the project is changed.

Easy marking of trusses and rafters based on properties and location ensures accurate bills of materials and accurate assembly. And information for fabrication can be automatically generated with all desired views, schedules, and drawings for each structural element.

Prefabricated Metal Frame Roof Panels


Automated Rafter Framing

Auto-generate complex roof truss systems
POWERFUL FEATURES

Truss+

STEEL ROOF TRUSS WIZARD FOR REVIT®

Generate light gauge steel truss systems for roofs of any shape, perform structural analysis, and auto-generate shop drawings. Functions of Metal Framing Truss+are versatile, parameters easy to control, and changes occur in real time. It’s a potent BIM workflow booster: no more drafting – just decide and design.

  • Build full metal truss systems in one go with the configurable 3D grid (escaping the limited and time-consuming nature of standard Revit truss family insertion).
  • Easily assess steel truss options, in economic and engineering terms, to make the best choices.
  • Create new parametric, uniquely-shaped truss families based on model lines and roofs for immediate use in your projects.
  • Freely revise your Revit model. Truss systems update and adapt.
  • Get real-time take-offs and views, auto-sorting and dimensioning, and optional export to CNC machines (Howick, Pinnacle, etc.) with C+C and C+U support.

Roof Panel Layout

PREFABRICATED ROOF PANELING

Enable easy roof panel planning and splitting into segments for prefabrication, which can then be used in the roof framing process.

  • Panel Layout Planning functions let you better understand how a roof will be divided. Users can control every division line and can predefine rules to automate the division process.
  • Initially an architectural roof can be divided into coarse partitions, or regions. Regions can be created automatically based on the ends of roof ridges and the bottom ends of valley rafters as well as windows and generic or system openings with predefined distances.
  • Regions can be divided into panels using predefined spacing.
  • Panels can be aligned and modified for an individual roof side or region and additionally split.
  • A variety of automated splitting functions make it easy to get the needed result. Panels can be split in half a variety of ways: by maximum spacing, from the middle to both ends, in the middle and to both ends, from the initially selected end, or from both ends.
  • Selected regions or panels can be joined, if needed.
  • Creates individual panels for the selected roof side or for the whole roof.
  • The full roof panels can later be taken to a new phase via their properties for better filtering and scheduling.

Roof+

for prefabricated panels

ROOF PANEL FRAMING

Automate metal framing roof work in Revit® projects. Robust features allow you to efficiently frame metal roofs, complete with roof joists, battens, valley joists, roof boards, and more. Plus, the software automates shop drawings, including sorting, tagging, dimensioning, and scheduling all frames.

  • Create your own rules and templates and use them for detailed, multi-layer, metal roof framing creation in Revit models.
  • Frame large roofs 10x faster than using regular Revit features.
  • Manage joists, rim joists, nogging, bridging, blocking, and bracing placement, and configure openings, details, service hole positions, and more.
  • Auto-distribute battens, secondary frames, and roofing.
  • Revise your Revit model as needed, simply by selecting the elements and properties you want to modify.
  • Track down structural and engineering clashes.
  • Cut and frame openings according to predefined rules.
  • Generate shop drawings and cut lists with just one click. Get real-time take-offs and views, plus automatic sorting and dimensioning.
  • Export to CNC machine.
  • Roof frames and shop drawings update and adapt to any changes.
  • Carry out structural analysis without leaving Revit.

Roof+

for rafter structures

RAFTER ROOF FRAMING

Automate metal framing work with rafter roofs in Revit® projects. Powerful, flexible, and easy to use. It helps you make optimal choices, move much faster, and avoid errors at every BIM stage – from design and
documentation to fabrication and construction.

  • Automatically split an architectural roof by faces.
  • Create detailed, multi-layer, metal rafter roof framing in a snap for your Revit model using fully customizable rules and templates.
  • Frame an entire roof based on its 3D model including hip/valley rafters, ridges, girders, collars, battens, horizontal beams, sleepers, trimmers, etc.
  • Auto-detect and frame roof openings, and cope ends of existing beams.
  • Freely revise your Revit model by easily selecting the elements and properties you want to modify.
  • Find structural and engineering clashes. Cut and frame openings according to predefined rules.
  • One-click generation of shop drawings and cut lists. Get real-time take-offs and views, plus automatic sorting and dimensioning.
  • Optional export to any CNC machine and CAD/CAM production line, such as Pinnacle, etc.
  • Roof frames and shop drawings update and adapt according to any changes.
  • Perform structural analysis without leaving Revit or export your metal frames to external analysis
    software at any stage of the design process.

Cut Opening

PRECISION OPENINGS FOR MEP SERVICES AND BUILDING STRUCTURES

Create openings with fire safety components throughout a Revit® model where ducts, pipes, cable trays and conduits intersect with walls, floors, roofs, ceilings, beams and columns. Cut Opening creates openings with special holding details for structural beams.

  • Automatically creates openings where ducts, pipes, cable trays, or conduits intersect walls, floors, roofs, ceilings, beams, or columns.
  • Automatically adds openings with predefined sizes in accordance with MEP line-based element sizes, categories, and system classifications.
  • Automatically joins openings with predefined configurations.
  • Automatically inserts Fire Dampers where ducts clash with walls, floors, ceilings, or roofs with fire rating.
  • Automatically inserts structural openings for separate architectural and structural models.
  • Enhances BIM-team work and deliverables for integrated project delivery (IPD).

Sort Mark

FLEXIBLE ELEMENT AND GRID RENUMBERING

Renumber Revit® elements just the way you want, detect and renumber grids, determine swing direction and orientation (and add them as properties), recalculate shared coordinates, and much more.

  • Detects and renumbers grid geometry.
  • Renumbers grids automatically after they have been changed in the project.
  • Powerful and flexible functions allow renumbering of any Revit elements (Doors, Windows, Beams, Columns, Pipes, etc.) in a number of different ways.
  • Writes swing direction for doors into the door’s properties.
  • Writes flip/mirror orientation for the selected elements.
  • Recalculates shared X, Y, Z coordinates.
  • Possibility of saving numbering settings under a separate name.
  • Possibility of sorting elements in ascending/descending order.
  • Creates new shared parameters, and many more functions.

Would you like a quote or a live demo given by one of our experts?


Want to find out if this is the right solution for you? Our professionals can help you quickly find out how this software will benefit your design process.

FRAME YOUR PROJECT!

Don’t waste time reading technical documentation, and see that this is the solution for you! Our Expert will frame a part of your project, demonstrate software functionality, and share best practices and the most efficient way of framing, taking into account your current needs.

Duration: 1 hour. Cost: 250$/250€

You’ll leave the demonstration with:

– Part of your project already framed;
– Your questions answered;
– 14-day software trial;
– Support during the trial period.

CLIENT STORIES

Scottish firm’s DfMA-level CLT Revit models benefit greatly from unique BIM softwareBela calls AGACAD metal framing and CNC solutions the “lifeblood” of its building design business
NIRAS A/S: “AGACAD’s Cut Opening software supports our Lean BIM processes”“AGACAD framing tools let us confidently take on more complexity”
Thorson Baker Associates logoTHORSON BAKER & ASSOCIATES (TBA): “AGACAD software has given substance to our models”JPS-Konsult: “We’re hooked on Precast Concrete and other AGACAD solutions”
AEC AB: “Partnership with AGACAD was key for implementing BIM fully at Trivselhus.”A-BET BV logoA-BET gets competitive boost in panelling, framing, BIM to fabrication with AGACAD solutions
More client stories >>AMV needed software to create shop drawings fast and check that frame members are correctly positioned

Developed in compliance with standards and guidelines:

AISI S100-07/S2-10, North American Specification for the Design of Cold-Formed Steel Structural Members with Supplement 2. American Iron and Steel Institute, Washington, DC.
AISI S200-07, 2007. North American Standard for Cold-Formed Steel Framing – General Provisions. American Iron and Steel Institute, Washington, DC.
NASH Standard – Residential and Low-rise Steel Framing, Part 1: Design Criteria. 2010.
NASH Standard – Residential and Low-rise Steel Framing, Part 2: Design Solutions. 2010.
Building Enclosure Design Guide– Wood Frame Multi-Unit Residential Buildings. Homeowner Protection Office (HPO), Vancouver, Canada, 2011.
AISI D110-07, Cold-Formed Steel Framing Design Guide, 2nd Edition. American Iron and Steel Institute, Washington, DC.
AISI D100-08, AISI Manual, Cold-Formed Steel Design. American Iron and Steel Institute, Washington, DC.
Pinnacle CNC Machine Specifications
Metroll Manufacturer and Supplier Resources
ClarkDietrich Steel Framing Product Specifications
CEMCO Specifications
